Vertical 3D Wall Printing Machine

This HD 3D vertical wall printing machine is built for professionals, decorators, artists, and businesses who want eye-catching wall visuals without the hassle of wallpaper or decals. With laser-accurate positioning, seamless image blending, and full CMYK+W support, it delivers unbeatable color clarity and realism on nearly any material.

Key Features & Benefits

Print on Almost Any Wall Type
Works perfectly on painted walls, brick, tile, cement, metal, wood, wallpaper, and more.

Real 3D/5D Effect Simulation
Add texture and realism to prints with simulated 3D visuals that pop off the wall.

High-Definition Precision
Adjustable DPI from 360 to 2880 ensures clear, sharp images—even at large sizes.

Fast & Flexible Output
Print up to 6m in length with a customizable height of 2.5m. Speed ranges from 6–14 m²/h.

CMYK + White Ink Printing
Print vibrant color with or without a white base. Better contrast and layering for bold designs.

Smart Auto Adjustments
Built-in sensors handle concave/uneven walls, detect gaps with 1mm precision, and keep prints aligned.

Portable & Stackable Design
Easily disassemble into 3 parts for transport. Lightweight and ready to go on-site.

Laser Positioning System
Helps precisely align designs for professional, straight-edge wall graphics.

Reliable Software
Supports PSD, JPG, PNG, TIF, and AI-PDF formats. Includes real-time data backup and nozzle condition detection.

What’s in the Box

1 x Vertical Wall Printing Machine (Model BK-UP1600A)

3 x 1m aluminum tracks

Built-in laser cross locator

24 x detachable guide rollers

5 x 500ml UV ink bottles (CMYK + White)

1 x Computer system

1 x Moisturizing solution

1 x Cleaning solution

1 x Ink blotter needle and head

User Manual and Technical Support Info

Technical Specifications

Print Size: 2.5m height × 6m length

Nozzle: Epson i1600 (Optional DX7, DX10, 4720)

Resolution: 360–2880 DPI

Print Speed: 6–14 m²/hour

Ink Type: UV (5 colors)

Input Formats: PSD, JPG, PNG, PDF, AI, TIF

Control: Wired via computer

Power: 350W, 110V–220V

Print Life: Up to 40,000 m² (with 4720 nozzle)

Weight: Main machine 15kg, track 4x8kg, base 15kg
